PTFE Stainless Steel Male RF Coaxial Connector Microwave 24.5mm Max

Brand Name : ELT (Elite)

Model Number : 3.5-J130G

Certification : CE Rohs ISO-9001

Place of Origin : China

MOQ : 100

Price : Negotiable

Payment Terms : T/T, Western Union, L/C

Supply Ability : 10000 Pieces Per Month

Delivery Time : Within in 3 weeks

Packaging Details : Standard Export Carton

Material : Stainless Steel

Keywords : 3.5mm Connectors

Characteristic Impedence : 50Ω

Gender : Female

Durability : 500 Cycles

Insulator : PTFE

Application : RF/Automotive/Base Station/ Radios /Satcom/Telecom

Frequency Range : DC~33GHz

Contact Now

Series 3.5mm milimeter wave RF Coaxial male connector

3.5mm connector is a common used millimeter wave connector, the frequency is 33GHZ (up to 36GHZ), use air interface, can mate and interchange with SMA series, K series connectors with advantages of great bandwidth, high reliability, it is widely used in microwave measurement and millimeter wave devices.

Electrical Characteristics
Impedance
50Ω
Frequency Range
DC~33GHz
Rated Voltage
335VRMS (Maximum sea-level)
Dielectrics Voltage-resistance
1000VRMS (Maximum sea-level)
Insulation Resistance
≥5000MΩ
Contact Resistance
Outer conductor
≤2mΩ
Center conductor
≤3mΩ
VSMR
≤1.01+0.05f

Interface Dimension(mm)

PTFE Stainless Steel Male RF Coaxial Connector Microwave 24.5mm Max

Outline Drawing:

PTFE Stainless Steel Male RF Coaxial Connector Microwave 24.5mm Max

Materials and Mechanical Properties
Inner conductor Male Brass, Gold-plating
Female Beryllium Bronze,Gold-plating
Elastic Beryllium Bronze,Nickel plated
Shell & other Brass/Stainless steel Gold-plating/passivated
Insulator PEI
Sealing ring Silicone rubber
Temperature -55C°~+125C°
Mating Cycles
500
Mating Torque
0.79N·m～1.13N·m
